gram-render

JEV-powered generative UI for Telegram bots. Describe the UI you want in natural language, hand over structured data, and get back a deterministic, validated GramSpec — a plain-JSON Telegram interface specification your bot can compile and send.

Try it live → t.me/gramrender_bot — a zero-typing playground: guided demo, fixture gallery, JSON playground, and /inspect to see every decision the evaluator made. Type any prompt; edit the result in place.

prompt + context  ──▶  gram-render  ──▶  GramSpec (JSON)

gram-render never talks to Telegram. No bot token, no transport, no update handling, no callback execution — it stops at the spec. You compile it (compileClassicMessage for classic HTML and compileRichMessage for Bot API 10.3 Rich Messages are included as reference compilers) and send it with any Bot API client.

How it works

Under the hood, composition runs on JEV (TypeSafe "System One") — a decision model that can only make calibrated discrete choices, never write text. That constraint is the safety property: every string in the output comes from your data or your prompt — gram-render never invents prose.

1. Derive — candidates are extracted from prompt + context: quoted prompt strings become headings/buttons, context scalars become field lines, status-shaped values get emoji variants, arrays get section-vs-list representation options, context.actions become buttons.
2. Select (one JEV call) — every derived group becomes a choice question in a single batched evaluation ("show as sections, as a list, or omit?"), plus a fulfillable gate. JEV answers all questions in parallel; assembly into a spec happens deterministically in code.
3. Layout (one JEV call, only when non-trivial) — block ordering, section membership, and keyboard-row grouping, applied as a stable sort.
4. Validate — the tree, prop schemas, and Telegram's real limits (4096-char text, 64-byte callback_data) are checked before anything is returned.

Editing an existing spec (initialSpec) runs a sequential operation loop (remove / replace / move / add / finish) instead — the same protocol shape proven by Vercel's json-render composer, adapted to Telegram's smaller UI surface.

Install

npm install gram-render

Node ≥ 20. The only runtime dependency is zod.

For AI coding assistants, an llms.txt index of the API ships in the package and lives at the repo root.

You need a TypeSafe API key (console.typesafe.ai). The default createEvaluator() reads it from its apiKey option, or from the GRAM_RENDER_API_KEY / TYPESAFE_API_KEY environment variables.

Quick start

import { render, createEvaluator, compileClassicMessage } from "gram-render";

// The default evaluator: resolves the TypeSafe API key (apiKey option, else
// GRAM_RENDER_API_KEY / TYPESAFE_API_KEY) and performs the JEV calls.
const evaluate = createEvaluator();

const result = await render({
  evaluate,
  prompt: 'Show this order. Quote "Order #1842" as the heading. Expose the actions.',
  context: {
    order: {
      id: "#1842", customer: "Maya Patel", status: "processing", payment: "paid",
      items: [
        { name: "Linen shirt", qty: 2, price: "$39.00" },
        { name: "Canvas tote", qty: 1, price: "$24.00" },
      ],
      total: "$102.00",
    },
    actions: [
      { label: "Mark as packed", action: "mark_packed",
        payload: { order: "#1842" }, style: "primary" },
      { label: "Cancel order", action: "cancel_order",
        payload: { order: "#1842" }, style: "danger" },
    ],
  },
});

if (result.stopReason === "finish" && result.spec) {
  const payload = compileClassicMessage(result.spec);
  // payload: { text, parse_mode: "HTML", reply_markup: { inline_keyboard } }
  // → send with your Bot API client of choice
}

A typical compiled message for this fixture (JEV chooses the layout, so details vary run to run):

<b>Order #1842</b>

<b>Order</b>
<b>ID:</b> #1842
<b>Customer:</b> Maya Patel
ℹ️ Status: processing
✅ Payment: paid
<b>Total:</b> $102.00
• Linen shirt
• Canvas tote

[Mark as packed] [Cancel order]   ← callback_data '["mark_packed",{"order":"#1842"}]'

Prompt-only renders

context is optional. With no data, the only content source is what you quote in the prompt — JEV composes the structure and picks the blocks, but it never authors a word:

const result = await render({
  evaluate,
  prompt: 'A tiny welcome card for the coffee shop "Daily Grind". Offer "Order pickup" and "Opening hours" as buttons.',
});

if (result.stopReason === "finish" && result.spec) {
  const payload = compileClassicMessage(result.spec); // same as before
}

A typical compiled message for that prompt (JEV chooses the layout, so details vary run to run):

<b>Daily Grind</b>

[Order pickup] [Opening hours]   ← callback_data 'order_pickup' / 'opening_hours'

A prompt with nothing quotable (no quoted strings, no context) returns stopReason: "unavailable" — an empty result instead of an invented card. That is the never-authors property working in both directions: quotes are the content, and without them there is nothing to show.

Streaming

composeSpec streams validated intermediate specs — useful for debugging, previews, and tooling. Telegram consumers can simply await the final event.

for await (const event of composeSpec({ prompt, context })) {
  if (event.type === "step") {
    console.log(event.step.kind, event.step.description, event.step.confidence);
    // event.spec — snapshot of the spec so far
  } else {
    console.log(event.stopReason, event.calls, event.inputTokens);
  }
}

Editing

Pass a generated (or hand-written) spec back with initialSpec and a follow-up prompt. Unaffected elements keep their ids and props — safe to diff and to re-send only what changed.

const edited = await render({
  prompt: "Remove the cancel action.",
  initialSpec: result.spec,
  context: { order },
});

API

render(options): Promise<RenderResult>

One-shot composition. RenderResult = { spec, stopReason, calls, elapsedMs, inputTokens, warnings, steps }.

composeSpec(options): AsyncIterable<CompositionEvent>

Streaming variant: step events (kind select | layout | edit, description, confidence, spec snapshot) then one complete event (final spec, stopReason, usage, warnings).

StopReason

• "finish" — spec produced.
• "unavailable" — JEV judged the request not fulfillable with the derived candidates (or all groups were omitted). spec may be null; these are normal outcomes, not exceptions.
• "limit" — edit loop hit maxSteps.

ComposeOptions

Option	Default	Meaning
prompt	— (required)	≤ 4000 chars. Quoted "…" strings become heading/button candidates.
context	—	Structured data. Every displayed string comes from here or the prompt.
initialSpec	—	Switches to the sequential edit loop.
evaluate	createEvaluator()	The evaluator used for every JEV call. Inject a custom Evaluator to override (same request shape as json-render's).
guidance	—	{ select?, layout?, edit? } nudges forwarded in evaluator state.
minConfidence	off	When set (0–1), a fulfillability answer below the gate returns unavailable (JEV signals near-coin-flips with very low confidence).
limits	see below	{ maxElements: 24, maxDepth: 3, maxCandidates: 40, maxSteps: 16, maxContextChars: 8000 }.
signal	—	Abort signal, propagated to every evaluator call.

createEvaluator(options)

The default evaluator — a ~100-line fetch wrapper for the TypeSafe API (no SDK dependency; gram-render ships with zod only). It is constructed automatically when evaluate is omitted, and exported so you can build it explicitly (as in the quick start), share one instance across calls, or configure it: apiKey? (else GRAM_RENDER_API_KEY / TYPESAFE_API_KEY), baseURL? (else TYPESAFE_BASE_URL; default https://api.typesafe.ai), model? (else TYPESAFE_DEFAULT_MODEL; default jev-latest), timeoutMs? (default 10 000), fetch? (inject a mock). HTTP errors surface as typed EvaluatorErrors; there are no internal retries.

GramSpec

A flat tree — one Message root, keyed elements, ordered children. Plain JSON, no JEV internals.

{
  "version": 1,
  "root": "m1",
  "elements": {
    "m1": { "type": "Message", "props": {}, "children": ["n1", "n2", "n3"], "keyboard": ["r1"] },
    "n1": { "type": "Heading", "props": { "text": "Order #1842" } },
    "n2": { "type": "Status",  "props": { "level": "info", "text": "Status: processing" } },
    "n3": { "type": "Section", "props": { "title": "Delivery" }, "children": ["n4", "n5"] },
    "n4": { "type": "Field",   "props": { "label": "Method", "value": "Courier" } },
    "n5": { "type": "Field",   "props": { "label": "ETA", "value": "Sep 23–24" } },
    "r1": { "type": "ButtonRow", "props": {}, "children": ["n6", "n7"] },
    "n6": { "type": "Button", "props": { "label": "Mark as packed", "action": "mark_packed", "payload": { "order": "#1842" }, "style": "primary" } },
    "n7": { "type": "Button", "props": { "label": "Cancel order", "action": "cancel_order", "payload": { "order": "#1842" }, "style": "danger" } }
  }
}

Components (the fixed Telegram catalog, shipped in-package)

Component	Props	Telegram mapping (classic HTML)
Message	preview?: "disabled"	the message body + one inline keyboard
Heading	text	bold line
Text	text	plain paragraph
Section	title	bold title + grouped lines
Divider	—	────────────── rule
Field	label, value, mono?	label: value line (mono → <code> value)
List	items[], ordered?	• /1. lines
Status	level: success|info|warning|error, text	✅ ℹ️ ⚠️ ❌ line
Code	text, language?	<pre><code> block
Quote	text, expandable?	<blockquote>
Alert	level, title?, text	emoji + bold title line
Table	columns?[], rows[][], compact?	monospace <pre> aligned grid
Note	text	small italic <i> hint line
ButtonRow	—	one inline-keyboard row
Button	label, exactly one of action/url, payload?, style? (primary|success|danger), disabled?	InlineKeyboardButton

Slot rules (enforced): only Message/Section take content children; only Message has keyboard; only ButtonRow inside keyboard; only Button inside ButtonRow; depth ≤ 3.

Schemas are exported (GramSpecSchema, per-component prop schemas, parseGramSpec) so hand-written or third-party specs validate against the same rules.

Compile targets

A spec is renderer-agnostic JSON. Two reference compilers ship in-package:

Classic — compileClassicMessage(spec)

const payload = compileClassicMessage(spec);
// { text, parse_mode: "HTML", reply_markup?: { inline_keyboard } }
await bot("sendMessage", { chat_id, ...payload });
await bot("editMessageText", { chat_id, message_id, ...payload }); // live views

Rich Messages — compileRichMessage(spec) (Bot API 10.1–10.3)

Compiles the same spec to real blocks — tables become RichBlockTables (with borders/compact), Note becomes a footer block, Quote.expandable a native collapsible, and Message.keyboard rows become in-flow buttons blocks:

const payload = compileRichMessage(spec);
// { rich_message: { blocks: [...] } }
await bot("sendRichMessage", { chat_id, ...payload });
await bot("editMessageText", { chat_id, message_id, ...payload });

Button semantics are identical in both targets: action + payload serialize to the same ≤64-byte callback_data, so a consumer's callback handler works unchanged across targets. Trade-off note: buttons ride inside the rich payload, so a plain-text fallback send (HTML-parse-recovery style) would lose them — rebuild a classic reply_markup from the spec if you need both.

Rich limits are enforced by inspectRichMessage / telegramDiagnostics(spec, "rich"): 32,768 chars of text, 500 blocks (list items and table rows count), 8 buttons per block, 20 table columns.

Actions & callback_data

action is a short consumer-defined identifier; payload is any JSON object. gram-render never executes actions — the spec records intent; your bot's callback handler owns behavior.

compileClassicMessage serializes action + payload as JSON.stringify([action, payload]) and errors above 64 bytes (Telegram's callback_data limit). Payloads that don't fit: store them server-side and reference by a short id.

Validation & errors

Four layers: derived-candidate checks, tree checks after every mutation (dangling/shared refs, slot rules, depth, budget), zod prop schemas, and a Telegram compile-check per target — classic: 4096-char text, 64-byte callback_data as errors, rows > 8 / buttons > 6 / text > 3500 as soft warnings; rich: 32,768-char text, 500 blocks, 8 buttons per block as errors, near-limit values as warnings.

• EvaluatorError — HTTP/timeout/protocol failures (cause preserved).
• CompositionError — defensive invariant violations.
• ValidationError — spec/limit violations, with code + elementId.

inspectClassicMessage(spec) / inspectRichMessage(spec) return diagnostics without throwing; telegramDiagnostics(spec, target?) is the same check as a linter.

Design notes

• Jev cannot invent text, and that's a feature. Every string is (a) context data, (b) a quoted prompt string, (c) a key-derived label, or (d) a catalog-standard label. Candidates carry literal props; JEV chooses among them and never authors content.
• Batched composition. All selection questions ride in one evaluation call (JEV evaluates questions in parallel), so a new spec costs ≈2 calls and an edit ≈1 call per operation.
• Deterministic assembly. Ordering uses a stable sort (ties keep candidate order); spec assembly, id assignment (n1, n2, …), and row grouping are pure code.
• Confidence is surfaced, not hidden. Near-coin-flip decisions show up in step.confidence; minConfidence turns them into unavailable when you'd rather ask the user than guess.
• Semantic catalog. The 15 components compile to classic HTML and Bot API 10.3 Rich Messages from one schema — the same spec renders on any Telegram client generation.

Testing

npm test                 # unit — fake evaluator, no network
npm run test:integration # real JEV (needs TYPESAFE_API_KEY), skipped otherwise
npm run example          # quickstart demo (needs TYPESAFE_API_KEY)
npm run live             # send + edit one live Telegram message (.env: TELEGRAM_BOT_TOKEN)
npm run bot              # interactive showcase bot (examples/demo-bot, same .env)
npm run smoke:rich       # live Rich Messages smoke + undocumented-behavior probes (same .env)

The test suite uses a scripted fake evaluator for deterministic composition/edit/assembly tests, plus env-gated integration tests against the live API.

Roadmap (v0.2+)

Multi-message Flow specs, media/poll/location blocks (transport-coupled — deferred), RichTextDateTime mapping for date values, checkbox list items, details-block catalog component, in-flow button positioning inside rich tables, custom catalog escape hatch, retry policies, RFC 6902 patch streaming for live-edit consumers, sendRichMessageDraft streaming previews.
